Features

Large 5684 can size to fit the demands of huge scale crawlers and scalers

FOC (Field-Oriented Control) geared up

Top quality 4-pole sintered rotor

Polarity security - magnetic encoder inside the motor warranties consistency in between 3 stages' signals and constantly outputs accurate signals indicated by rotor position. When setting up simply match wire color to esc adapters

4mm gold plated bullet adapters

Water resistant sensor wire with locking plug and gasket

Top quality building and construction with accuracy ball bearings and hardened steel 5mm output shaft





Overview
The Firma 1200Kv Sensored Brushless Motor is a terrific choice for huge scale crawlers, rock racers, and trailers operating on two – 4S LiPo power. Specificly sourced for the Axial® SCX6™ platform to provide the ultimate performance for maximum power and realism. Including a low cog 4-pole 8-magnet rotor style, CNC machined aluminum housing, insulated high pureness copper windings, top quality alloy steel 5mm output shaft, and accuracy bearings for high toughness and smooth rotation. Preinstalled with 4mm gold plated bullet adapters for simple installation.

The SPEKTRUM FIRMA 120A SENSORED BRUSHLESS SMART CRAWLER ESC IS REQUIRED.



Specifications

Application: 1/6 Rock Crawling

Forward: Yes

Optimum Constant Present: 80A

Motor Type: Brushless

External Diameter: 2.2" (56 mm)

Product Length: 3.3" (84 mm)

Reverse: Yes

RPM/Volt (Kv): 1160

Voltage: 4S/15V
