Spektrum A6310 Ultra Torque High Speed Metal BL HV Servo

Introduction

Features
•High Voltage (HV) capable (6.0-8.4v input range)
•Impressive torque and speed in a basic servo size (350 oz-in and .10 sec/60° @8.4v)
•Durable and long-term brushless motor
•Low wear and securely meshed all metal equipment train
•Dual bearing supported drive train assists take full advantage of smooth operation
•Aluminum center servo case assists keep running temperatures low
•Soft start assists avoid part and airframe damage throughout un-intentional initializations
•Over Current and Temperature protection
•Helpful initialization start tone lets pilot know when the servo is ready
•Integrated servo failsafe holds last known position if signal is lost and power is preserved
•Frequency : 50-400hzSpektrum™ high-voltage, brushless servos deliver reliable power and digital precision with incredible efficiency. Finely tuned electronics and software combine with powerful brushless motor technology to offer ultra-smooth efficiency more efficiently than servos with traditional motors. The aluminum center section permits any heat within the servo to dissipate quickly while high-strength metal gears and high-impact polymer case elements deliver an accuracy instrument that’s problem-free.The Spektrum A6310 utilizes this strong structure, plus extra inner support, to attain an outstanding balance of power, resilience and value, in addition to the peace-of-mind over-current and over-temperature protection offers. It’s a brilliant feature mix that makes this servo an outstanding choice for 60-120cc Aerobatic designs and a lot of sport flying Giant Scale models.

Specifications

Type: Digital
Torque: 192.4 oz-in (13.8 kg-cm) @ 6.0V; 324.3 oz-in (23.3 kg-cm) @ 7.4V; 350.0 oz-in (25.2 kg-cm) @ 8.4V
Speed: 0.12 sec/60 deg @ 6.0V; 0.11 sec/60 deg @ 7.4V; 0.10 sec/60 deg @ 8.4V
Length: 37.8mm (1.49in)
Width: 20.0mm (0.79in)
Height: 40.0mm (1.57in)
Weight: 2.5 oz (71 g)
Bearing: Dual
Motor Type: Brushless
Equipment Type: Metal
Voltage: 6.0-8.4V
