Tamiya 1/10 Rc Avante 4Wd Buggy Kit (2011)

This is the radio managed, electric powered, 1/10 scale
Tamiya Avante 2011 Off-Road Buggy Kit.

FEATURES:
Chassis: 0.08" (2mm) thick carbon fiber, double deck configuration
Own: Four wheel shaft with pin-secured wheel axles
Body: Polycarbonate with wing and chassis fairing
Motor: 25 turn brushed
Electronic Speed Control: TEU-104BK
Shocks: Oil-filled with gold colored cylinders and bottom caps for
    simple upkeep
Shock Stays: 0.14" (3.5mm) thick carbon fiber
Suspension: Front and rear multi-link double wishbone, adjustable
    metal arms with radius arm protectors and rear anti-roll bar,
Differentials: Front and rear planetary, center ball diff
Tires: High-grip pin spike with foam inserts
Wheels: Front, 1" (25.4mm) wide, 2.2" (57mm) size
Rear, 1.4" (35.5mm) wide, 2.2" (57mm) size, likewise
    4 1.4" (35.5mm) wide, 2.2" (57mm) size cam-loc wheels with
    wheel caps
Caster: Adjustable caster/toe-in refers to the angle of the front
    suspension when seen from the side of the vehicle in relation to the
    chassis
Steering: Bell-crank type with servo saver and adjustable linkage

CONSISTS OF:
Tamiya Avante 2011 Off-Road Buggy Kit with ESC, 25T motor, oil-filled
    shocks, 22 tooth pinion, set of tradional buggy wheels, set of
    cam-loc wheels, spike tires with inserts, body, decal sheet and
    instruction manual

REQUIRES:
Radio: 2-channel with one guiding servo
Battery: 6-cell stick pack with standard adapter
Battery charger: AC/DC Timed or Peak for 6-cell battery

SPECIFICATIONS:
Lorry;
Length: 16.5" (420mm)
Width: 9.4" (240mm)
Height: 4.5" (140mm)
Wheelbase: 10.2" (260mm)
Tread: 7.9" (200mm) distance from wheel centers, delegated right
Gear Ratio: 1:8.33
Minimum Ground Clearance: 1.6" (40mm)
Weight: 2.9pounds (1300g)
    Body:
Length: 13" (330mm)
Width: 5.9" (150mm)
Height: 2.4" (61mm)

REMARKS:
To paint body to match automobile on box, order the following Tamiya
    colors;
    TAMR8616, PS-16 Metallic Blue TAMR8118, X-18 Semi Gloss Black
    TAMR5017, TS-17 Gloss Aluminum TAMR1707, XF-7 Flat Red
    TAMR8106, X-6 Orange TAMR1766 XF-66 Light Grey

For Replacement Ball Bearings usage:
Qty. Size Area Qty. Bearing Set
1 5x11mm Gearbox 1 DTXC1547
1 5x8mm Gearbox 1 DTXC1523
2 8x16mm Front Differential 1 DTXC1535
2 2x6mm Front Differential 1 DTXC1501
2 8x16mm Rear Differential 1 DTXC1535
2 3x8mm Rear Differential not carried
2 5x8mm Rear Counter Gear 1 DTXC1523
1 5x11mm Center Diff 1 DTXC1547
1 5x8mm Center Diff 1 DTXC1523
4 5x11mm Rear Axle 2 DTXC1547
4 5x11mm Front Axle 2 DTXC1547
