Overview
Running in the rough and topple environment of 1/5 scale, a servo's efficiency is pushed to the maximum. The S9110BL and S9120BL servos have been created to give 1/5 enthusiasts substantial torque and brushless motor accuracy, taking their driving experiences to a brand-new level.
Starting with a brand-new case style with enhanced assistance for pins holding the equipments, and a brand-new aluminum leading plate with re-designed bearing home, the S9110 and S9120 have been style for enhanced toughness. A brand-new brushless motor style will give more power than any previous Spektrum servos – the high torque S9120 is ranked at 1454 oz-in of torque at 8.4v, while the high speed S9110 is ranked at 1224 oz-in of torque. The S9110 keeps a comparable speed of 0.14 sec/60° at 8.4, while having practically 60% more torque than the previous version! Extra enhancements include a smooth new stealth black style and new thicker 18awg wire removable adapter. What's more, both are already race proven, the S9110BL and S9120 having won the 2020 1/5 Worlds Buggy Class at So Cal Nitro.
No matter if you pick the higher speed S9110BL or the higher torque S9120BL, these servos will give higher efficiency and extra control whether racing your 1/5 vehicle on the track or slamming through dunes.



Specifications

Application: 1/5 scale off-road

Bushing Or Bearing: Bearing

Connector Wire Gauge: 18 AWG

Connector Wire Length: 6 in (152mm)

Deadband: Micro sec: <>

Gear Product: Steel

Height: 1.84 in (27.2mm)

Length: 2.47 in (62.7mm)

Motor Type: Brushless

Servo Operating Voltage: 6.0 - 8.4V (HV)

Servo Size Classification: Custom-made

Speed: 0.21 sec/60 deg @ 6.0V, 0.16 sec/60 deg @ 7.4V, 0.14 sec/60 deg @ 8.4V

Spline Count: 15 Teeth

Torque: 867 oz-in (62.43 kg-cm) @ 6.0V, 981.75 oz-in (70.69 kg-cm) @ 7.4V, 1224.3 oz-in (88.16 kg-cm) @ 8.4V

Type: Surface

Weight: 6.3 oz (178.6g)

Width: 1.18 in (30mm)
