Spektrum Firma 160 Amp Smart Brushless Marine ESC 3S - 8S

.mediaFeature [padding:2px 0;]
.safeTech [background:#6f92a5; float:left; padding:10px; margin:10px; font-size: 17]
.safeTech, .safeTech h4 [color:#fff;]

.aligncenter [
text-align: center;
]





Features

Smart all-in-one telemetry

Quick, powerful 32-bit ARM M4 processor

160 Amp Constant existing, best for requiring high voltage setups

Approximately 8S (29.6V) input voltage

Built in Series Connection with high heat resistant IC5 Connectors

No compromise waterproof design

Several water cooling coats provide adequate heat dispensation

Several alternatives for easy programming:

Button programming

Smart ESC Programs Box

SmartLink USB Updating and Programmer application

Multi-point defense:

Over-current defense

Automatic LiPo low-voltage cutoff

Thermal defense

Failsafe defense

Compact for easy installation in many applications

All set to install — no soldering required

Rugged plastic case with mounting tabs

Aluminum heat sink for high performance

Several water cooling inlets/outlets

High existing 6V BEC

Firmware updatable through the Smart ESC Programs Box

High heat-resistant IC™ adapters, in reverse compatible with EC™ adapters

Limited 1-year service warranty

Developed and created by Spektrum™ engineers, in partnership with the industry's leading ESC maker





Overview
Like every component in the Spektrum™ Smart ecosystem, Firma™ Smart ESCs integrate "plug-and-play" simpleness with the capability to interact with other Smart electronic devices — together, producing the best-performing RC system for your car imaginable.
Firma Smart ESCs do a lot more than regulate power. They operate like a virtual engineer inside your design, providing a direct path to the crucial operating information you need to reach peak performance. Firma Smart ESCs give you an additional layer of self-confidence that your electronic devices are all running at their best.
With Firma Smart ESCs, you'll be much better connected to your car than ever before — without installing additional parts that all work individually of each other. You will not need additional wires, modules, or links. A Firma electronic speed control provides a one-wire service for obtaining telemetry information such as RPM, temperature, battery voltage and capacity.
Firma ESCs not just gather the information but likewise send it to your transmitter in genuine time, instead of just keeping it for after-run research study. You're able to change settings as required to improve performance on the go. The Firma Smart single-wire telemetry service has actually been evaluated for quality and performance by the best brands in RC. Their verdict? Smart innovation is both easier and superior!





Needed to Complete

Spektrum Surface Area Receiver

Spektrum Smart Technology LiPo Battery

Spektrum Transmitter

Please check out the link listed below for complete details:
Spektrum Smart Compatibility Matrix

What remains in package?

(1) Spektrum™ Firma™ Smart ESC

(1) Spektrum Smart Sticker sheet

(1) Item Manual









Spektrum™ Smart Technology









WATERPROOF
The Firma Marine ESCs are thoroughly created and evaluated to provide a water-tight seal when run in almost any fresh water environment. Perfectly fit for RC boat applications in a large series of sizes and capabilities. Please note it is not recommended to run in salt water and ocean shore environments.




EC3™/EC5™ BACKWARDS COMPATIBLE
Firma™ ESCs feature IC™ series battery adapters. The IC series of adapters are created from the ground up to provide a more solid connection, greater heat resistance, and simple and easy installation. When utilized with an IC3™ or IC5™ connector-equipped Spektrum™ Smart battery, the ESC can receive and transfer battery telemetry information. EC3 and EC5 are likewise compatible with Firma ESCs for fundamental operation and ESC telemetry.










ONE-WIRE TELEMETRY
No requirement to connect several wires, sensing units, modules, and links. With Firma™ ESCs, basic one-wire telemetry sends a wide range of information directly to your transmitter in genuine time, including RPM, voltage, temperature, balance, and capability utilized*
*See compatibility chart to find out more.






SMART TECHNOLOGY BATTERY DATA
When utilized with a Spektrum™ Smart LiPo battery, your Firma™ ESC provides you with the benefit of battery telemetry that's instantly transmitted to your compatible Spektrum radio in genuine time. On your transmitter screen you'll be presented with helpful information such as variety of cycles, battery capability utilized and staying, specific cell voltage and more!




MULTIPLE PROGRAMMING OPTIONS
Several programming alternatives are available. Button programming can be utilized with absolutely nothing more required. Utilizing the Smart Firma™ ESC Programs Box, you can easily alter settings at the track to suit driving conditions. An easy-to-use Smart Link USB Updating and PC Programmer app is likewise available.










FAST, POWERFUL M4 PROCESSOR
The Firma™ ESCs' 32-bit M4 processor produces greater resolution signal input and more accurate motor output.





Requirements

Auto Cutoff: Y

Battery Connector: IC5

Battery Input Lead: IC3, 10 AWG, length, 7.9 in (200mm)

BEC: Yes

BEC Continous Current: 8A

BEC Type: Change mode

Brakes: No

Forward: Yes

Height: 1.4 in (35.5mm)

Input Voltage: 11.1 - 29.6V (3S -8S LiPo)

Length: 3.7 in (95.7mm)

Motor Connector: 6.5mm Bullet

Overload Security: yes

Reverse: Yes

Type: Brushless marine ESC w/dual battery adapters

Weight: 9.9 oz (280g)

Width: 3.5 in (90.4mm)
