Associated Reflex 14B RTR Buggy 4WD Combo

.mediaFeature [cushioning:2px 0;]
.safeTech [background:#3c454c;float:left;padding:20px 0;font-size: 17]
.safeTech, .safeTech h4 [color:#fff;]





Key Features

2.4GHz 2-channel radio system

High-Torque Digital Servo with spring-style servo saver

Powerful Reedy 4500kV Brushless Motor

Waterproof, high-power, Reedy brushless speed control with T-plug connector

Three sealed differentials

Threaded, coil-over shock absorbers

Adjustable turnbuckles

Adjustable inserts for caster blocks and rear hubs

Aluminum guiding rack

Front universal driveshafts

Streamlined and elegant race-inspired body





Required to Complete

Four (4) AA batteries (#302 Reedy AA Alkaline Batteries)

What remains in the Box?

(1) Reflex 14B Ready-To-Run Buggy

(1) Reedy Wolfpack 7.4V 1600mAh 30C TWO LiPo Battery with T-Plug connector

(1) Reedy 423-S Compact Balance Charger

(1) Multi-Wrench

(1) Spare Hardware

(1) Item Handbook





Overview
Team Associated's 1:14 scale REFLEX 14B 4WD electric buggy comes out of the box currently assembled, with a Reedy Power brushless speed control and motor, high-torque digital steering servo, and 2.4GHz radio system. With all that power at your disposal, the buggy's style easily channels it into 4WD enjoyable! The adjustability provided by the turnbuckles, caster blocks, and rear hubs make the REFLEX 14B all set for any surface you can throw at it. Extra functions include three sealed differentials, aluminum steering rack, and lightweight aluminum center driveshaft. Including a battery pack of your option to the REFLEX 14B RTR, you can now have big efficiency in a small Ready-to-Run package!













Requirements

Approximate Assembly Time: Less than 1 Hour

Batteries: 7.4V 1600mAh 30C TWO LiPo

Battery Measurements: 100x30x20mm

Charger: Reedy 423-S 2S/3S LiPo AC Charger

Completion Level: Ready-To-Run

Drivetrain: 4WD

Internal Gear Ratio: 2.46:1

Length: 11.97 in. (304mm)

Motor Type: 4500kV Brushless, Brushless

Radio: XP 2.4GHz 2 channel radio

Size/Scale: 1/14

Speed Control: SC300-BL Brushless BEC ESC

Lorry Type: Buggy, Buggy

Wheel Hex Size: 12mm Hex

Width: 7.95 in. (202mm)
