Align M470 Multicopter Super Combo Promotion

Will be offered quickly.
February 1st to March 15th





















Requirements:
After times of looks into and advancement, Align R&D team devoted all its technical proficiency and experiences into the advancement of a brand brand-new aerial photography platform, to bring to life the brand brand-new. Standard Devices:
G2 Gimbal x 1
Multicopter Canopy x 1
7 Inch Main Rotor x 4 Sets
External Status LED x 1
BL4213(370KV) Brushless Motor x 4
Multicopter Brushless ESC x 4
PCU Power Control System x 1
APS-M Multicopter Controller x 1
Multicopter GPS Sensor x 1
6S1P 22.2V 6000mAh/30C HBP60001 X 1

Requirements:
Airframe Size: 710mm
Height: 266mm
Main Blade Length: 179mm
Main Rotor Size: 391mm
Flying Weight(without battery): 2500g

G2 Gimbal Requirements:
Input Voltage: DC 12V(THREE)
Current Draw: <500mA
Maximum Control Range:
PAN 340?
ROLL ?20?
TILT 120?
Maximum Control Rotation Rate:
PAN 60?/s
ROLL 60?/s
TILT 60?/s
Temperature Range: -20~80?C
Voltage Output：5V / 0.3A
Dimension: 100.4x74x111.5mm
Weight: Approx. 200g

APS-M Flight Control System Introduction:
Brand new APS-M Flight Control System with superior performance through cutting edge information technologies, utilizing high precision sensors and modern system control subroutines. Support quad(4), hex(6), and octo(8) rotors. Flight modes include attitude, GPS velocity, GPS angular, intelligent, and manual. In addition, it features failsafe auto return home, low voltage failsafe (through LED indicator and auto Return Home), OSD signal output, gimbal control, and Point of Interest (POI) function.
Compatible with PC and Bluetooth interface, could be easily adjust flight parameter and update firmware at any time.

APS-M Flight Control System Features:
Brand new APS-M flight control system with higher performance, precision sensors and superior reliability platform.
APS-M supports 4, 6, and 8 rotors multicopters, with flight modes such as Manual, Attitude, GPS (angular), GPS (speed).
Equipped with automatic return home function with remote activation ability from R/C transmitter. When RC transmitter signal is lost, multicopter will automatically fly back to home position.
APS-M provides 3 intelligent flight modes: CFO, HCL, and POI.
Provides real-time OSD flight data output function.
RoHS certified.
Compatible with PC and Bluetooth interface, could be easily adjust flight parameter and update firmware at any time.
Also fully support with Futaba, Spektrum and JR S. BUS/S.BUS and DSM2/DSMX/DSMJ/DMSS system.

APS-M Flight Control System Specification:
Input Voltage:DC 4.5~8.4V
Operating Current Consumption:<250mA @ 4.8V
Operating Frequency：400Hz
Operating Temperature：-20℃~65℃
Hovering Precision (Depending on Satellite Status)：Horizontal ?1m Vertical ?1m
Maximum Flight Speed：Horizontal 15m/sec Vertical 6m/sec
Maximum Altitude Restriction：700m(2297ft) above the takeoff point
Maximum Angular Speed：
Aileron 115?/sec
Elevator 115?/sec
Rudder 145?/sec
Maximum Tilting Angle：30 degrees
Supports External Peripherals："G2/ G3 Gimbal、OSD+FPV Video Transmitter "
Supports Multicopter Configurations："4 rotors +, 4 rotors X, 6 rotors +, 6 rotors X, 8 rotors +, 8 rotors X."
Dimension：49x34.3x20mm

PCU Power Control Unit:
Input Voltage：13.2V~25.2V(4S~6S Li-Po)
Operating Frequency：500KHz
Dimension：62x35x26mm

BL4213 Motor 370KV(RPM/V):
Input Voltage：DC 22.2V
Max Continuous Current：25A
Max Continuous Power：550W
Stator Arms：12
Magnet Poles：14
Dimension/Weight：φ4xφ52x33mm / 185g

Motor ESC:
Input Voltage：13.2V~25.2V(4S~6S Li-Po)
Max Continuous Current：40A
Dimension：74.2x27x12.7mm

Please Click here for Download APS-M
